What is SW7 Extracorporeal Shock Wave Therapy Device?

The SW7 is a high-precision, non-invasive shockwave therapy system designed to treat musculoskeletal pain and promote tissue regeneration. Using advanced capacitor-based technology, it generates mechanical shockwaves that penetrate skin and soft tissues, reaching both superficial and deep layers.

Ideal for human musculoskeletal rehabilitation and veterinary therapy, the device provides accurate treatment with minimal discomfort. Sessions are short, typically around 10 minutes per targeted area, and no drugs or invasive procedures are required.

SW7 can also assist in Erectile Dysfunction (ED) therapy by enhancing blood flow and stimulating tissue regeneration within the penile region. Its ergonomic design and user-friendly interface allow efficient clinical operation and session monitoring.

Technical Principles

1. Shockwave Generation
High-energy capacitors store and rapidly release energy, producing mechanical shockwaves. This process ensures consistent and powerful energy delivery.

2. Focused Energy Delivery
Interchangeable applicator heads allow precise focusing of shockwaves to depths ranging from 0 to 70 mm. This technology ensures accurate targeting of affected muscles, tendons, and joints while sparing surrounding tissues.

3. Biological Effects

• Enhances microcirculation and oxygenation in treated tissues

• Activates fibroblasts and osteoblasts, accelerating tissue repair

• Relieves pain and muscle tension

• Supports natural regeneration without harming healthy tissues

4. Adjustable Parameters

• Energy: 4.5–50J

• Frequency: 60–120 pulses/min

• Trigger mode: Continuous or single pulse

• Penetration depth: 0–70 mm

Treatment Procedure

1. Assessment
   Evaluate the patient’s condition and identify target areas. Adjust energy and frequency according to treatment goals.

2. Preparation
   Apply coupling gel to the treatment area to optimize energy transmission.

3. Application
   Deliver shockwaves using the handpiece. Treatment per area lasts about 10 minutes.

4. Post-Treatment
   Monitor patient response. Advise rest and schedule follow-up sessions. Maintain a minimum 72-hour interval between treatments.

Recommended Therapy Course:

• Acute Pain: 1–3 weeks

• Chronic Conditions: 4–5 weeks, additional sessions may be needed

• Patient Considerations: Younger patients may require shorter cycles; older or complex cases may need extended therapy

Device Specifications

Contraindications

• Patients with heart disease or pacemakers

• Acute inflammation, deep vein thrombosis, or malignant tumors

• Pregnant women

• Regions with metallic implants or recent cosmetic surgery

• Severe edema, skin inflammation, or immune system disorders

Applications

• Relief of musculoskeletal pain (shoulder, knee, hip, elbow, ankle)

• Rehabilitation and sports injury recovery

• Erectile Dysfunction (ED) therapy

• Veterinary musculoskeletal treatment

• Physical therapy and functional recovery

Focused vs Radial Shockwave

Focused Shockwave (F-SWT)

• Penetrates deeply to target joints, tendons, and hidden pain points

• High energy density for precision treatment

• Ideal for chronic musculoskeletal conditions

Radial Shockwave (R-SWT)

• Shallow penetration, disperses energy across a larger surface area

• Suitable for superficial muscles, myofascial pain, or widespread tension

• Provides comfort but limited effect on deep tissues

FAQ

Q1: Is shockwave therapy safe?
Yes, SW7 uses mechanical waves and emits no radiation.

Q2: Is the treatment painful?
Most patients feel mild tingling or pressure. Settings can be adjusted for comfort.

Q3: How long should sessions last?
Each session lasts about 10 minutes per treatment area.

Q4: What is the recommended interval between treatments?
Maintain at least 72 hours to allow tissue recovery.

Q5: Can pets use this therapy?
Yes, the device is suitable for veterinary musculoskeletal therapy.

Q6: Are there maintenance requirements?
Regularly clean the device, replace water, and monitor handpiece and capacitor lifetimes.

​
